2R230TD-8

Specialized Resistors

GDTSurge ProtectionTelecom

The 2R230TD-8 is a 230V, 20kA gas discharge tube (GDT) optimized for high-speed telecom and power line surge protection.

Best for

  • Telecom lines
  • Data communication equipment
  • Power supplies

Avoid if

  • High-frequency signal lines where capacitance must be extremely low
  • Applications exceeding 230V DC operating voltage

Check before use

  • Ensure the circuit's maximum operating voltage is below the GDT's spark-over voltage.

Key specifications

DC Spark-over
230V
Impulse Current
20kA
Capacitance
<1.5pF

Compliance & Environment

RoHS
Compliant
REACH
Compliant
MSL
-
ECCN
-
HTSUS
-

Application

TelecomPower
