E2SB16E000014E product

E2SB16E000014E

Resonators

SMD Crystal2520 PackageHosonic

The E2SB series is a compact 2.5x2.0mm SMD crystal designed for high-density applications like Bluetooth and Wireless LAN.

Best for

  • Bluetooth modules
  • Wireless LAN
  • Office automation equipment

Avoid if

  • Applications requiring extreme temperature ranges beyond -30°C to +85°C

Check before use

  • Load capacitance matching
  • Reflow soldering profile

Key specifications

Frequency Range
12MHz - 62.5MHz
Package
2.5 x 2.0 mm
Height
0.65 mm

Compliance & Environment

RoHS
Compliant
REACH
-
MSL
-
ECCN
-
HTSUS
-

Application

ConnectivityConsumer Electronics

Datasheet

fb84ec83c33b4672da6858c281fa7dfe_HOSONIC(鸿星)&E2SB16E000014E.pdf

800 KB

Datasheet AI

CAD Models

Download ECAD models for E2SB16E000014E: KiCad symbol & footprint, Altium footprint, PCB footprint, and 3D model.

EDA Symbol
Schematic symbol for your EDA tool
Get Files
PCB Footprint
Land pattern for PCB layout
Get Files
3D Model
STEP file for mechanical design
Get Files
KiCad Library
Verified KiCad 8 symbol, footprint, and 3D model
Generate library

Login required · CAD models billed separately as an add-on

Alternative components

Alternatives are being enriched. Analyze this part in PartGenie for the latest matches.

Design and risk insights

Questions & answers

The E2SB series is a line of seam-sealed SMD crystal units from Hosonic, characterized by a compact 2.5mm x 2.0mm footprint and a low profile of 0.65mm.
