E6C1205RYGC2UDA-A02 product

E6C1205RYGC2UDA-A02

LED Indication - Discrete

Bi-color LEDSMDRed/Green

The E6C1205RYGC2UDA-A02 is a compact, bi-color (Red/Yellow Green) surface-mount LED suitable for status indication and backlighting in portable and consumer electronics.

Best for

  • Status indicators
  • Backlighting
  • Wearable devices

Avoid if

  • High-sulfur environments
  • Applications requiring high-power illumination

Check before use

  • Moisture sensitivity level (MSL) storage requirements

Key specifications

Color
Red / Yellow Green
Package
3.2mm x 2.0mm
Viewing Angle
130°
Forward Voltage
2.0V

Compliance & Environment

RoHS
Compliant
REACH
Compliant
MSL
3
ECCN
-
HTSUS
-

Application

Consumer ElectronicsIndustrial Indicators

Datasheet

9d277b7505d74b64f6fbdbdb48b804fc_2210131730_EKINGLUX-E6C1205RYGC2UDA-A02_C5197656.pdf

800 KB

Datasheet AI

CAD Models

Download ECAD models for E6C1205RYGC2UDA-A02: KiCad symbol & footprint, Altium footprint, PCB footprint, and 3D model.

EDA Symbol
Schematic symbol for your EDA tool
Get Files
PCB Footprint
Land pattern for PCB layout
Get Files
3D Model
STEP file for mechanical design
Get Files
KiCad Library
Verified KiCad 8 symbol, footprint, and 3D model
Generate library

Login required · CAD models billed separately as an add-on

Alternative components

Alternatives are being enriched. Analyze this part in PartGenie for the latest matches.

Design and risk insights

Questions & answers

It is a bi-color surface-mount LED from Ekinglux that emits both Red and Yellow Green light.
