MCS20FC-1R0MCY-A

Chokes

Power InductorSMD0806

The MCS20FC-1R0MCY-A is a 1.0 uH molded power choke in an 0806 package, suitable for high-density power management circuits.

Best for

  • Power supply modules
  • DC-DC converters

Avoid if

  • Applications requiring high-current saturation beyond 3.0 A

Check before use

  • Thermal derating at +125°C

Key specifications

Inductance
1.0 uH
Irms (Typical)
2.70 A
Isat (Typical)
3.00 A

Compliance & Environment

RoHS
Compliant
REACH
Compliant
MSL
-
ECCN
-
HTSUS
-

Application

Power

Datasheet

f92d54b8b4363f7ab431b606efc741e9_2312012005_PSA-Prosperity-Dielectrics-MCS20FC-1R0MCY-A_C19273343.pdf

800 KB

Datasheet AI

CAD Models

Download ECAD models for MCS20FC-1R0MCY-A: KiCad symbol & footprint, Altium footprint, PCB footprint, and 3D model.

EDA Symbol
Schematic symbol for your EDA tool
Get Files
PCB Footprint
Land pattern for PCB layout
Get Files
3D Model
STEP file for mechanical design
Get Files
KiCad Library
Verified KiCad 8 symbol, footprint, and 3D model
Generate library

Login required · CAD models billed separately as an add-on

Alternative components

Alternatives are being enriched. Analyze this part in PartGenie for the latest matches.

Design and risk insights

Questions & answers

It is a molded power choke inductor manufactured by Prosperity Dielectrics (PSA) with an inductance of 1.0 uH.
