MHCI06024-4R7M-R8A product

MHCI06024-4R7M-R8A

Chokes

Power InductorMoldedSMD

The MHCI06024-4R7M-R8A is a 4.7µH molded power inductor from Chilisin, rated for 10A saturation current and 5A RMS current.

Best for

  • DC/DC power conversion
  • High-density power supplies

Avoid if

  • Applications exceeding 10A peak current
  • Space-constrained designs not compatible with 06024 footprint

Check before use

  • Thermal dissipation in high-current operation

Key specifications

Inductance
4.7 µH
Isat
10 A
Irms
5.0 A
RDC (Max)
50 mΩ

Compliance & Environment

RoHS
Compliant
REACH
Compliant
MSL
-
ECCN
-
HTSUS
-

Application

Power Management

Datasheet

1859215b843d66daad423ca7c29763f3.pdf

800 KB

Datasheet AI

CAD Models

Download ECAD models for MHCI06024-4R7M-R8A: KiCad symbol & footprint, Altium footprint, PCB footprint, and 3D model.

EDA Symbol
Schematic symbol for your EDA tool
Get Files
PCB Footprint
Land pattern for PCB layout
Get Files
3D Model
STEP file for mechanical design
Get Files
KiCad Library
Verified KiCad 8 symbol, footprint, and 3D model
Generate library

Login required · CAD models billed separately as an add-on

Alternative components

Alternatives are being enriched. Analyze this part in PartGenie for the latest matches.

Design and risk insights

Questions & answers

It is a molded magnetic shielded power choke with an inductance of 4.7µH, designed for high-density surface-mount applications.
