PR03000201002JAC00 product

PR03000201002JAC00

Through Hole Resistors

Power ResistorMetal FilmThrough Hole

The PR03000201002JAC00 is a 3W, 10kΩ power metal film resistor from Vishay, suitable for general-purpose power and automotive applications.

Best for

  • Power supplies
  • Automotive circuits
  • Lighting ballasts

Avoid if

  • Space-constrained designs requiring smaller packages

Check before use

  • Maximum operating voltage and ambient temperature derating

Key specifications

Resistance
10 kΩ
Power Rating
3 W
Tolerance
±5%
Max Voltage
750 V

Compliance & Environment

RoHS
Compliant
REACH
Compliant
MSL
-
ECCN
-
HTSUS
-

Application

PowerAutomotive

Datasheet

Vishay-company-15.pdf

800 KB

Datasheet AI

CAD Models

Download ECAD models for PR03000201002JAC00: KiCad symbol & footprint, Altium footprint, PCB footprint, and 3D model.

EDA Symbol
Schematic symbol for your EDA tool
Get Files
PCB Footprint
Land pattern for PCB layout
Get Files
3D Model
STEP file for mechanical design
Get Files
KiCad Library
Verified KiCad 8 symbol, footprint, and 3D model
Generate library

Login required · CAD models billed separately as an add-on

Where to Buy

Real-time and catalog pricing from verified distributors

Live prices updated on demand · Catalog (~) prices may differ

Alternative components

Alternatives are being enriched. Analyze this part in PartGenie for the latest matches.

Design and risk insights

Questions & answers

It is a 3W power metal film resistor with a resistance of 10kΩ and a tolerance of ±5%.
