S6320000181050 product

S6320000181050

Resonators

CrystalSMD20MHz

The JGHC S6320000181050 is a 20MHz SMD crystal in a 6035 package, ideal for wireless and mobile applications requiring high frequency stability.

Best for

  • Bluetooth modules
  • Wireless communication
  • Mobile devices

Avoid if

  • Applications requiring extreme temperature ranges outside -10°C to +70°C

Check before use

  • Load capacitance matching

Key specifications

Frequency
20 MHz
Package
6035
Tolerance
±30 ppm

Compliance & Environment

RoHS
Compliant
REACH
-
MSL
-
ECCN
-
HTSUS
-

Application

Wireless ConnectivityConsumer Electronics
