SMMS1360-470M

Chokes

ShieldedPower InductorSMDHigh Current

The SMMS1360-470M is a 47µH shielded power inductor optimized for high-current DC/DC applications.

Best for

  • DC/DC power conversion
  • High-current POL converters

Avoid if

  • Space-constrained designs requiring smaller footprints

Check before use

  • Peak current requirements
  • Thermal dissipation

Key specifications

Inductance
47 µH
Saturation Current
6 A
DCR (Max)
70 mΩ
Package
1360

Compliance & Environment

RoHS
Compliant
REACH
Compliant
MSL
-
ECCN
-
HTSUS
-

Application

Power ManagementIndustrial

Datasheet

57b06dfee49b8b2b037d260d03598bf7.pdf

800 KB

Datasheet AI

CAD Models

Download ECAD models for SMMS1360-470M: KiCad symbol & footprint, Altium footprint, PCB footprint, and 3D model.

EDA Symbol
Schematic symbol for your EDA tool
Get Files
PCB Footprint
Land pattern for PCB layout
Get Files
3D Model
STEP file for mechanical design
Get Files
KiCad Library
Verified KiCad 8 symbol, footprint, and 3D model
Generate library

Login required · CAD models billed separately as an add-on

Alternative components

Alternatives are being enriched. Analyze this part in PartGenie for the latest matches.

Design and risk insights

Questions & answers

It is a shielded molding surface-mount power inductor with 47µH inductance, designed for high-current power management circuits.
