SRP1270-100M

Chokes

ShieldedPower InductorSMD

The Bourns SRP1270-100M is a shielded power inductor providing 10 µH inductance and 10 A rated current, suitable for DC/DC converters and power supplies.

Best for

  • DC/DC converters
  • Power supplies

Avoid if

  • New designs (use SRP1265A instead)

Check before use

  • Availability of newer series

Key specifications

Inductance
10 µH
Rated Current
10 A
Saturation Current
16 A
DCR
16.8 mΩ

Compliance & Environment

RoHS
ROHS3 Compliant
REACH
-
MSL
1
ECCN
EAR99
HTSUS
8504508000.0

Application

Power SuppliesDC/DC Converters

Datasheet

COLCS00390-1.pdf

800 KB

Datasheet AI

CAD Models

Download ECAD models for SRP1270-100M: KiCad symbol & footprint, Altium footprint, PCB footprint, and 3D model.

EDA Symbol
Schematic symbol for your EDA tool
Get Files
PCB Footprint
Land pattern for PCB layout
Get Files
3D Model
STEP file for mechanical design
Get Files
KiCad Library
Verified KiCad 8 symbol, footprint, and 3D model
Generate library

Login required · CAD models billed separately as an add-on

Where to Buy

Real-time and catalog pricing from verified distributors

Live prices updated on demand · Catalog (~) prices may differ

Alternative components

Alternatives are being enriched. Analyze this part in PartGenie for the latest matches.
