SRP6540-1R0M

Chokes

ShieldedPower InductorSMD

The Bourns SRP6540-1R0M is a shielded power inductor providing 1 µH inductance and 12 A RMS current, ideal for high-density power management applications.

Best for

  • DC/DC converters
  • Laptop power supplies

Avoid if

  • Applications requiring extremely low DCR or non-shielded inductors

Check before use

  • Thermal dissipation on PCB

Key specifications

Inductance
1 µH
I rms
12 A
DCR (Max)
7.2 mΩ

Compliance & Environment

RoHS
ROHS3 Compliant
REACH
-
MSL
3
ECCN
EAR99
HTSUS
8504508000.0

Application

Power Management

Datasheet

Bourns-company-36.pdf

800 KB

Datasheet AI

CAD Models

Download ECAD models for SRP6540-1R0M: KiCad symbol & footprint, Altium footprint, PCB footprint, and 3D model.

EDA Symbol
Schematic symbol for your EDA tool
Get Files
PCB Footprint
Land pattern for PCB layout
Get Files
3D Model
STEP file for mechanical design
Get Files
KiCad Library
Verified KiCad 8 symbol, footprint, and 3D model
Generate library

Login required · CAD models billed separately as an add-on

Where to Buy

Real-time and catalog pricing from verified distributors

Live prices updated on demand · Catalog (~) prices may differ

Alternative components

Alternatives are being enriched. Analyze this part in PartGenie for the latest matches.

Design and risk insights

Questions & answers

It is a shielded power inductor from Bourns, featuring an iron powder core, designed for high-current DC/DC conversion.
