VR37000001004FA100

Through Hole Resistors

High VoltageMetal GlazeLeadedAEC-Q200

The VR37000001004FA100 is a 1 MΩ, 0.5 W high-voltage metal glaze resistor from Vishay, ideal for high-stability applications.

Best for

  • High-voltage power supplies
  • Automotive control circuits
  • White goods

Avoid if

  • Applications requiring extremely low noise or very high precision beyond ±1%

Check before use

  • PCB creepage and clearance distances for 3500 V operation

Key specifications

Resistance
1 MΩ
Tolerance
±1%
Power Rating
0.5 W
Max Voltage
3500 V

Compliance & Environment

RoHS
Compliant
REACH
Compliant
MSL
-
ECCN
-
HTSUS
-

Application

Power SuppliesAutomotive
