WSC251520R00FEA

Chip Resistor - Surface Mount

WirewoundSurface MountAEC-Q200

The WSC251520R00FEA is a 1W, 20Ω wirewound surface mount resistor from Vishay, designed for high-stability power applications.

Best for

  • Automotive electronics
  • Industrial power supplies

Avoid if

  • Space-constrained designs requiring ultra-low profile components

Check before use

  • Thermal derating curves for high ambient temperatures

Key specifications

Resistance
20 Ω
Power Rating
1 W
Tolerance
±1%

Compliance & Environment

RoHS
Compliant
REACH
-
MSL
-
ECCN
-
HTSUS
-

Application

AutomotiveIndustrial
