WSR5R0200FEA

Chip Resistor - Surface Mount

AEC-Q200Current SensingPower Metal Strip

The WSR5R0200FEA is a high-performance 20 mΩ, 5W Power Metal Strip® resistor from Vishay, ideal for automotive and industrial current sensing.

Best for

  • Automotive current sensing
  • High-power industrial circuits

Avoid if

  • Space-constrained designs requiring smaller footprints

Check before use

  • PCB thermal pad design

Key specifications

Resistance
20 mΩ
Power Rating
5 W
Tolerance
±1%

Compliance & Environment

RoHS
Compliant
REACH
-
MSL
-
ECCN
-
HTSUS
-

Application

AutomotivePower Management
