XL-2106SURC product

XL-2106SURC

LEDs - Discrete

SMD LEDRed LED0802

The XL-2106SURC is a compact 0802 SMD red LED optimized for automated SMT assembly.

Best for

  • Consumer electronics
  • Automotive indicators
  • PCBA

Avoid if

  • High-moisture environments without proper baking
  • Manual soldering without temperature control

Check before use

  • Reflow profile settings
  • MSL storage requirements

Key specifications

Color
Red
Intensity
80-240 mcd
Voltage
1.7-2.3 V
Dimensions
2.1 x 0.55 x 1.0 mm

Compliance & Environment

RoHS
Compliant
REACH
-
MSL
3
ECCN
-
HTSUS
-

Application

Consumer ElectronicsAutomotive

Datasheet

2b71e8c14fcd7d069c5f8c3b78e5dd43_2402181506_XINGLIGHT-XL-2106SURC_C965867.pdf

800 KB

Datasheet AI

CAD Models

EDA symbol, PCB footprint, and 3D model for this component. Supported tools include Altium, KiCad, Eagle, and more.

EDA Symbol
Schematic symbol for your EDA tool
Get Files
PCB Footprint
Land pattern for PCB layout
Get Files
3D Model
STEP file for mechanical design
Get Files

Login required · CAD models billed separately as an add-on

Alternative components

Alternatives are being enriched. Analyze this part in PartGenie for the latest matches.

Design and risk insights

Questions & answers

It is a high-brightness red LED in an 0802 surface-mount package.
