XL-Z1921RGBA-SG product

The XL-Z1921RGBA-SG is a compact, high-brightness RGB LED in a 1921 surface-mount package, suitable for various consumer and automotive display applications.

Best for

Consumer electronics
Automotive displays
Decorative lighting

Avoid if

High-vibration environments without proper stress relief

Check before use

Moisture sensitivity level (MSL 3) storage requirements

Key specifications

Package: 1921 (2.0 x 2.1 x 1.9 mm)
Forward Current: 20 mA
Viewing Angle: 120°

Compliance & Environment

RoHS: Compliant
REACH: -
MSL: 3
ECCN: -
HTSUS: -

Application

Consumer ElectronicsAutomotive

Datasheet

c52b33895f73eb56ea23c5147642baff_2406131539_XINGLIGHT-XL-Z1921RGBA-SG_C22461785.pdf

800 KB

CAD Models

Download ECAD models for XL-Z1921RGBA-SG: KiCad symbol & footprint, Altium footprint, PCB footprint, and 3D model.

EDA Symbol

Schematic symbol for your EDA tool

PCB Footprint

Land pattern for PCB layout

3D Model

STEP file for mechanical design

KiCad Library

Verified KiCad 8 symbol, footprint, and 3D model

Generate library

Alternative components

Alternatives are being enriched. Analyze this part in PartGenie for the latest matches.

Design and risk insights

Questions & answers

It is a high-brightness RGB LED designed for SMT assembly, featuring a black matte package for improved contrast.
